ARIEL Four Cylinder Model 4G Mk.II 1956-1957 Price List for Spare Parts #E162

ARIEL  1956-1957  Square Four Model 4G Mk.II   Reproduction of the Supplementary Price List of Spare parts, 13 pages.  #E162/B

Note that this price list was done several years ago so these prices are no longer accurate.  This supplement can be used to identify parts.  It has exploded views of the parts with their part numbers.

Content:

Crankcase & fittings / Pistons & fittings / Timing gear / Timing gear cover & fittings / Oil pump / Prop stand / Exploded view of the front wheel hub assembly / Gearbox type GB7 / Front wheel & hub assembly / Exploded view of the front wheel assembly / Front fork assembly / Steering head fittings / Handlebar & fittings / Control cables / Front mudguard & stand fittings / Petrol tank & fittings / Speedometer / Spring frame / Footrest & brake pedal / Rear mudguard / Oil tank & fittings / Detachable rear wheel / Front crash bars / Rear crash bars / Tool box & tool kit

The photocopy of this price list is not very nice but it is complete.
