BSA B40 CL10L C12 C15 D1 D3 D5 D7 125/150/175 Two-Stroke "D" Group Models Compellation of Service Sheets #E87
Couldn't load pickup availability
BSA 125/150/175 Two-Stroke "D" Group Models: B40 / CL10L / C12 / C15 / D1/ D3 / D5 / D7 Factory Compellation of Service Sheets, 84 pages NOS New Old Stock. #E87/B-E122/A
Contains the following Service Sheets:
No. 412C - D3 / D5 / D7 / C12 / C15 / B40 Swinging Arm Models Rear Suspension
No. 501A - Revised May 1965 D Group Gear Ratios
No. 502 - Revised March 1965 Models D1 / D3 / D5 / D7 The Petroil Lubrication System
No. 503 - Reprinted March 1966 Models D1 / D3 / D5 / D7 Engine adjustments which can be carried out without dismantling
No. 504 - Reprinted November 1965 Models D1 / D3 / D5 / D7 Engine dismantling for decarbonising
No. 505 - Revised February 1960, Reprinted October 1965 Models D1 / D3 Plunger D5 / D7 Swinging arm Removing engine-gear unit from frame and complete dismantling
No. 506 - Reprinted July 1966 Models D1 / D3 / D5 / D7 Re-assembly of the engine-gearbox unit
No. 507 - Revised June 1959, Reprinted April 1965 Models D1 / D3 / D5 / D7 Primary transmission
No. 508 - Reprinted June 1966 Models D1 / D3 / D5 / C10L Dismantling and re-assembly of the hubs and brakes
No. 509 - Reprinted November 1965 Models D1 / D3 / D5 / C10L up to 1956 (for C10L 1956 onwards, see Service Sheet No. 706) Removal and dismantling of the front forks and steering head
No. 510 - Revised June 1959, Reprinted March 1965 Models D1 / D3 / D5 / D7 Useful data
No. 511 - October 1948, Reprinted June 1964 Models D1 / D3 Workshop Data
No. 514 - This Sheet supersedes No. 814, Reprinted March 1966 "D" and "C" Group Models Plunger type rear suspension
No. 515 - Model 7 Dismantling and reassembly of hubs and brakes
No. 516 - Model 7 Front forks and steering head
No. 704 - All Models Piston clearances
No. 708 - All Models Carburation, monobloc and seperate float chamber type
No. 708B - Reprinted March 1966 All Models Carburation at high altitudes
No. 708C - Reprinted October 1964 "D" Group Models Carburation
No. 709 - All models Fault finding
No. 710 - October 1948 All Models Chain alterations and repairs
No. 808B - Reprinted September 1966 "D" Group Models Wiring diagrams
No. 808E - 1956 "D" Group Models Wiring diagrams
No. 808L - Model D7 (Coil Ignition) Wiring diagram
No. 810 - Model D1 (up to engine number YD1-40660) Wico-pacy "Geni-Mag" equipment
No. 810A - Models D1 / D3 / D5 Wipac flywheel ignition generator Series 55 Mark 8
No. 811 - December 1948, Reprinted March 1966 Models D1 / D3 / D5 / D7 / CL10L Lamps (Wipac Lighting)
This manual is in excellent condition.
