SUZUKI DR DS FA FR FZ GN GS GSX GT PE RS SP TR TS Z models 1982 1/2 Wiring Diagrams 99512-01820-01E #336

SUZUKI   Z models  1982 1/2  Factory Wiring Diagrams Manual, 181 pages  OEM Ref. # 99512-01820-01E   NOS  New Old Stock.   #336/B

Printed in February 1982

This manual is intended to aid Suzuki dealers in tracing wiring circuits and trouble shooting electrics on 1982 Suzuki "Z" model motorcycles.  These wiring diagrams are contained  in all specifications for Suzuki motorcycles distributed in the world.

Note that at the time this 1982 1/2 Wiring Diagrams manual was produced, it didn't cover all of the 1982 model year Z model motorcycles.

The supplementary 1982 2/2  Wiring Diagrams was published for the purpose of supplementing the 1982 1/2, hence, if the two manuals are used in conjunction, all of the 1982 model year motorcycles will be covered completely.  See 99512-01821-01E for that 1982 2/2 supplementary manual.

Models covered:

DR400S  DR500  DR500S

DS50  DS80

FA50  FR80  FR80D  FZ50

GN400  GN400L  GN400T  GN400TD

GS400L  GS400T GS450E  GS450L  GS450T  GS500  GS550M  GS550T  GS650E  GS650G  GS650GL  GS650GT  GS750E  GS750S  GS750T  GS850G  GS850GL  GS1100E  GS1000S  GS1100G  GS1100GL  GS1100S

GSX400F  GSX750S  GSX1000S  GSX1100S

GT80L  GT125X4  GT250X7

PE175  PE250  PE400  RS175  SP500

TR-SU  TR-SG  TR125U  TR125G

TS50ER  TS50ERK  TS50XP TS80ER  TS185ER  TS250ER

Although this is a NOS Manual, the cover shows shelf ware, however the inside is clean and in excellent condition.
