SUZUKI DR DS FZ GS GSX PE SP TS 1980 1/2 Wiring Diagrams Manual SR-0021 #346

SUZUKI  T Models 1980 1/2   Factory Wiring Diagrams Manual,  111 pages  OEM Ref. # SR-0021  NOS  New Old Stock.  #346/A

Printed in February 1980

This manual is intended to aid in tracing wiring circuits and troubleshooting electrics on 1980 Suzuki "T" model motorcycles.  These wiring diagrams are contained in all specifications for Suzuki motorcycles distributed in the world.

Note that in order to include all the T model motorcycles, an other manual was reproduced; the 1980 2/2  (SR-0022)  for the 1980 T model motorcycles that are not included in the 1980 1/2 manual.

Models covered:

DR400T  DR400ST

DS50T  DS80XT  DS100T  DS125T  DS185T  DS250T

FZ50T

GS400T  GS450T GS400LT  GS450LT  GS450ST  GS550T  GS550LT  GS750T  GS750LT  GS850GT  GS850GLT   GS1000HT  GS1000DT  GS1000ET  GS1000ST  GS1100T  GS1100LT

GSX250T  GSX400T  GSX400LT  GSX750T  GSX750LT  GSX1100T  GSX1100LT

PE175T  PE250T  PE400T

SP400T

TS50ERKT  TS50ERPT  TS100T TS100ERT  TS125T  TS125ERT  TS185T  TS185ERT  TS250T TS250ERT

This manual is in excellent condition.
