SUZUKI DS DR GS JR PE RM SP TS 1978 Wiring Diagrams Manual 99923-00738 #342

SUZUKI  1978  C Models  Factory Wiring Diagrams Manual,  21 pages  2nd Edition  OEM Ref. # 99923-00738  NOS  New Old Stock.    #342/F-B131/B

This manual is intended to aid in tracing wiring circuits and trouble shooting electrics on 1978 Suzuki C model motorcycles.  These wiring diagrams are for specifications for Suzuki motorcycles distributed in the U.S. and Canada.

Models covered:

DS80C  DS100C  DS185C  DR370C

GS400C  GS400XC  GS550C  GS550EC  GS750C  GS750EC  GS1000C  GS1000EC

JR50C

PE175C  PE250C

RM50C  RM80C  RM100C  RM125C  RM250C2  RM400C

SP370C

TS100C  TS125C  TS185C  TS250C

The cover of this NOS Manual has some shelf ware, however the inside is clean and in excellent condition.
